The Nebulizer is designed to provide aerosol medication therapy for the effective treatment of

bronchial asthma, acute bronchitis, and other respiratory ailments. The piston compressor nebulizer

converts liquid medication into mist (aerosols) for easy and effective inhalation. The nebulizer’s high

nebulization rate causes aerosols to reach deep lung tracts and low residual volume results in low

wastage of the medicine.

Specifications:

1. Particle size: ≥ 5µm

2. Machine noise ≤ 65dB

3. Residual liquid: 0.7ml

4. Medicine chamber capacity: 7ml

5. Average rate of spray: 0.2ml/min

6. Working pressure range: 30Kpa-60Kpa

7. Compressor motor specifications:

a. Winding type: Aluminium with copper coating

b. No. of wire turns: 2080

8. Package dimensions:

a. 175 x 110 x 250 mm (mini+)

b. 200 x 110 x 300 mm (prime+)

c. 175 x 110 x 250 mm (Ultra)

9. Package weight:

a. 1.4 kgs (mini+)

b. 1.52 kgs (prime+)

c. 1.4 kgs (Ultra)

Features:

1. Reaches deep lung tracts providing better results for medication.

2. Low medication wastage.

3. Suitable for both children and adults- contains a full set of accessories.

4. For treatment of lung infections in children and adults.

5. For treatment of COPD and cystic fibrosis.

Operation:

1. The box contains the following:

a. Compressor machine

b. Kit components- (Adult and child mask, mouthpiece, connecting tube, medicine

chamber)

c. 4 extra filters

d. User manual

2. Open the medicine chamber and fill the prescribed dose of medicine. (max capacity: 7ml)

3. Attach one end of the connecting tube to the compressor machine and the other end to the

medicine chamber.

4. As per the medical practitioner’s prescription, attach the desired inhalation attachment-

(Adult mask or Child mask or Mouthpiece)

5. Plug in the socket and turn on the compressor switch. ( The compressor noise and indicating

LED in the switch should be evident)

6. Keep the chamber in an upright position and inhale the spray from your attachment.

7. After use, turn off the compressor empty the medicine cup chamber, and wash it.
